CML Innovative Technologies is one of the largest worldwide suppliers of miniature lighting solutions,
CML Innovative Technologies is a vertically integrated designer, manufacturer and seller of the widest
selection of miniature lighting systems and components.

Light through full industrial capabilities
From Research & Development, initial design and raw material purchase to high speed customized
manufacturing and worldwide distribution, CML Innovative Technologies maintains total control
over the entire process


LEDS

LEDS-ESPA%C3%91A
Power LEDs Thru Hole LEDs SMD LEDs
Power-LEDs-Espa%C3%B1a Thru-hole-LEDS-espa%C3%B1a SMD-LEDs-Espa%C3%B1a
Displays
Displays-LED-espa%C3%B1a

LED products

LEDS-PRODUCTS-ESPA%C3%91A
LEDules Acsentios
LEDULES-ESPA%C3%91A ACSENTIOS-ESPA%C3%91A

Lamps & LED-lamps

LAMPS-AND-LED-LAMPS-ESPA%C3%91A
LED lamps Incandescent lamps Neon lamps
LED-lamps-CML Incandescent-LAMPS-CML Neon-lamps-CML

Indicators

INDICATORS-ESPA%C3%91A
LED indicators Neon Indicators Accessories
LED-indicators-CML Neon-indicators-CML Neon-indicators-CML-accesories

Custom products

Custom-products-Espa%C3%B1a
LED assembly
LED-assembly-Espa%C3%B1a





datasheet

Catalogo-de-lamparitas-para-se%C3%B1alizacion-y-pilotos-LED-de-CML





Catalogues

Ilumination


CML_Acsentio_4_pager CML%20LEDs%20II
Acsentios Flyer LEDules II

Incandescent lamps

cml_als
Automotive light sources catalogue

Indication




preview_cml_catalogue_2014

CML_IT_Classics
LEDs Lamps for Signalisation, LED Panel Mount Indicators LED indication 2017: Mega StarLEDs, StarLEDs, MultiLEDs, Indicators
ProductOverview08 Catalogue_Uni%20StarLEDs
CML Product Overview 2008 Uni StarLEDs - HighPower LED - lamps
Flyer_StarLEDs_warm_white
Warm white LEDs-Lamps catalogue


Aviation Lamps


preview_CML-IT_Aviation_Brochure
Lamps for Aviation application
Medica Lamps
preview_CML-IT_Medical_Lamp_catalogue_2014 preview_CML-IT_Medical_Lamp_catalogue_edition_2
Lamps for medical applications 2nd edition Lamps for medical applications






   Descargarse la guía de productos de CML




Cat.LEDULES de CML

Descargarse

Cat. de CML de transporte

Descargarse





CML Innovative Technologies suministra a sus clientes con componentes de iluminación en miniatura y solucioones de LEDs para un ámplio rango de mercados y aplicaciones. Trabajando en iluminación desde 1910,  CML Innovative Technologies es uno de los mayores y globales jugadores en dos unidades de negocio:

Iluminación multimercado - iluminación para el automovil

CML es líder en soluciones LED de innovación y nuestro equipo está enfocado hacia el diseño, producción y distribución de funeste miniatura de iluminación y sistemas de iluminación. Nuestra experiencia y nuestra ingeniería fabricación a nivel mundial nos permite continuar con los requisitos de nuestros clientes.



  Descargarse catálogos de CML:




Display per page
Sort by

Star LED 1856035W; CML-IT T20x46; Colour: White

Product no.: 1856123W

Star LED 1856035W; CML-IT T20x46; Colour: White; Voltage: 230V AC/DC; Typ.Current: 3mA; Typ.Lumi.Intensity: 6 x 290mcd; Dom.Wavelength: 6000K; Lamp base in accordance to DIN EN 60061-1: BA15d;

1504145W3D; CML-IT, StarLED, T5.5k LED-Lamp, 28V AC/DC

Product no.: 1504145W3D

1504145W3D; CML-IT, StarLED, T5.5k LED-Lamp, 28V AC/DC

Multiled, Series:15130 (T-1 3/4, 6,1x15,9mm, MG, 6, Yellow)

Product no.: SL E15130352
Size(inch): T-1 3/4
Size(mm): T6
Housing Size: 6,1x15,9mm
Base: MG
Chip number: 6
Chip color: Yellow

Wavelength(mA): 585
Op.voltage(V): 24
Rectifier: Bridge
AC current: 10
DC current: 10
Type lv DC current: 42
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18580 (T-6 1/4, 20x46mm, BA15d, 9, Green)

Product no.: SL E18580351
Size(inch): T-6 1/4
Size(mm): T20
Housing Size: 20x46mm
Base: BA15d
Chip number: 9
Chip color: Green

Wavelength(mA): 525
Op.voltage(V): 24
Rectifier: Bridge
AC current: 45
DC current: 45
Type lv DC current: 1000
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Array module, Series:LM-Axxx-1x1 Series (30x30, Blue, 5, 470, 120º)

Product no.: SL ELM-A05B-1X1
Size: 30x30
Color: Blue
Number Led: 5
Dom wave length: 470
Viewing Angle(º): 120º
lv per LED: 148

Op.voltage(V): 24
Power Consump.: 0,4
Voltage tolerance(%): 0,1
Op.Temp.(ºC): from -40ºC to 55ºC
Storage temp.: from -40ºC to 55ºC




RoHS Compliant

Multiled, Series:18130 (T-3 1/4, 10x28mm, BA9s, 8, Red)

Product no.: SL E18310350
Size(inch): T-3 1/4
Size(mm): T10
Housing Size: 10x28mm
Base: BA9s
Chip number: 8
Chip color: Red

Wavelength(mA): 620
Op.voltage(V): 24
Rectifier: Bridge
AC current: 16
DC current: 16
Type lv DC current: 110
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Multiled, Series:18130 (T-3 1/4, 10x28mm, BA9s, 8, Green)

Product no.: SL E18310351
Size(inch): T-3 1/4
Size(mm): T10
Housing Size: 10x28mm
Base: BA9s
Chip number: 8
Chip color: Green

Wavelength(mA): 567
Op.voltage(V): 24
Rectifier: Bridge
AC current: 16
DC current: 16
Type lv DC current: 110
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Multiled, Series:18130 (T-3 1/4, 10x28mm, BA9s, 8, Yellow)

Product no.: SL E18310352
Size(inch): T-3 1/4
Size(mm): T10
Housing Size: 10x28mm
Base: BA9s
Chip number: 8
Chip color: Yellow

Wavelength(mA): 585
Op.voltage(V): 24
Rectifier: Bridge
AC current: 16
DC current: 16
Type lv DC current: 115
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18580 (T-6 1/3, 20x46mm, BA15d, 9, Green)

Product no.: SL E18580352
Size(inch): T-6 1/3
Size(mm): T20
Housing Size: 20x46mm
Base: BA15d
Chip number: 9
Chip color: Green

Wavelength(mA): 525
Op.voltage(V): 24
Rectifier: Bridge
AC current: 45
DC current: 45
Type lv DC current: 1000
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18580 (T-6 1/3, 20x46mm, BA15d, 9, White)

Product no.: SL E1858035W
Size(inch): T-6 1/3
Size(mm): T20
Housing Size: 20x46mm
Base: BA15d
Chip number: 9
Chip color: White

Wavelength(mA): 0,31/0,32
Op.voltage(V): 24
Rectifier: Bridge
AC current: 45
DC current: 45
Type lv DC current: 750
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18580 (T-6 1/3, 20x46mm, BA15d, 9, White)

Product no.: SL E1858123W
Size(inch): T-6 1/3
Size(mm): T20
Housing Size: 20x46mm
Base: BA15d
Chip number: 9
Chip color: White

Wavelength(mA): 0,31/0,32
Op.voltage(V): 230
Rectifier: Halfwave
AC current: 4
DC current: -
Type lv DC current: 200
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18600 (T-6 1/4, 10x25mm, BA9s, 1, White clear)

Product no.: SL E1860035W3
Size(inch): T-6 1/4
Size(mm): T10
Housing Size: 10x25mm
Base: BA9s
Chip number: 1
Chip color: White clear

Wavelength(mA): 0,31/0,32
Op.voltage(V): 24
Rectifier: Halfwave
AC current: 9
DC current: 17
Type lv DC current: 1700
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Starled, Series:18607 (T-3 1/4, 10x25mm, E10, 1, White clear)

Product no.: SL E1860723W3
Size(inch): T-3 1/4
Size(mm): T10
Housing Size: 10x25mm
Base: E10
Chip number: 1
Chip color: White clear

Wavelength(mA): 0,31/0,32
Op.voltage(V): 230
Rectifier: Halfwave
AC current: 3
DC current: -
Type lv DC current: 300
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

MegaStarLED, Series:18620 (T-3 1/4, 10x25mm, BA9s, 3, Green)

Product no.: SL E18620451
Size(inch): T-3 1/4
Size(mm): T10
Housing Size: 10x25mm
Base: BA9s
Chip number: 3
Chip color: Green

Wavelength(mA): 525
Op.voltage(V): 28
Rectifier: Halfwave
AC current: 5
DC current: 10
Type lv DC current: 1500
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

MegaStarLED, Series:18630 (T-5, 16x35mm, BA15d, 3, Yellow)

Product no.: SL E18630352
Size(inch): T-5
Size(mm): T16
Housing Size: 16x35mm
Base: BA15d
Chip number: 3
Chip color: Yellow

Wavelength(mA): 587
Op.voltage(V): 24V AC/DC
Rectifier: Bridge
AC current: 17mA
DC current: 17mA
Type lv DC current: 3x340mcd
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

MegaStarLED, Series:18640 (T-5, 16x35mm, BA15d, 6, White clear)

Product no.: SL E1864035W3
Size(inch): T-5
Size(mm): T16
Housing Size: 16x35mm
Base: BA15d
Chip number: 6
Chip color: White clear

Wavelength(mA): 0,31/0,32
Op.voltage(V): 24-28V AC/DC
Rectifier: Bridge
AC current: 32-42mA
DC current: 32-42mA
Type lv DC current: 6x1600-2100mcd
Voltage tolerance(%): 0,1
Op.temperature: from -20ºC to 60ºC
Storage temp (ºC): from -25ºC to 80ºC
RoHS Compliant

Array module, Series:LM-Axxx-1x1 Series (30x30, White, 5, 0,31/0,31, 110º)

Product no.: SL ELM-A05W-1X1
Size: 30x30
Color: White
Number Led: 5
Dom wave length: 0,31/0,31
Viewing Angle(º): 110º
lv per LED: 520

Op.voltage(V): 24
Power Consump.: 0,3
Voltage tolerance(%): 0,1
Op.Temp.(ºC): from -40ºC to 55ºC
Storage temp.: from -40ºC to 55ºC




RoHS Compliant

Array module, Series:LM-Axxx-1x1 Series (60x120, White, 40, 0,31/0,31, 110º)

Product no.: SL ELM-A05W-2X4
Size: 60x120
Color: White
Number Led: 40
Dom wave length: 0,31/0,31
Viewing Angle(º): 110º
lv per LED: 520

Op.voltage(V): 24
Power Consump.: 2,4
Voltage tolerance(%): 0,1
Op.Temp.(ºC): from -40ºC to 55ºC
Storage temp.: from -40ºC to 55ºC




RoHS Compliant
*
